Compact Embodied-AI Quadruped Robot
FX Navi is a compact embodied-AI quadruped robot designed for young creators, education, research, coding exploration, and hands-on robotics development. It provides an accessible platform for learners to build, personalize, program, and experiment with robotics projects.
Dynamic 12-DOF Movement
Navi features a 12-DOF motion structure powered by 12 joint motors, with dynamic gait balancing and adjustable motion parameters. It can reach speeds of up to 2 m/s and rotate at up to 360° per second, supporting agile movement during robotics experimentation.
Obstacle Clearance & Runtime
Designed primarily for indoor, flat-ground use, Navi can clear obstacles up to 34 cm. Its built-in lithium battery provides approximately two hours of continuous operation, while direct charging is supported with a US-spec plug.
Open Development Ecosystem
Navi provides open development interfaces and a range of tools for exploring robotics and AI. Depending on the development setup, users can access visual programming, SDK/API integration, Brain Blocks, Create Studio, EAI Soul, EAI Scribe, EAI Studio, and a Python SDK.
Motion, Perception & Hardware APIs
The platform provides low-level interfaces for motion control and perception, along with APIs for hardware expansion. OTA updates further support ongoing feature development and platform improvements.
AI & Smartphone-Connected Features
Navi supports app connectivity, remote control, and smartphone-assisted capabilities. These can include access to a camera, microphone, display, LLM, and VLM functions, expanding opportunities for interactive AI and robotics projects.
Creative & Personalized Learning
With its neutral chassis and soft bionic body wrap, Navi can be customized with creative skins and 3D-printed head modules. Users can also explore personality design and other hands-on projects while learning robotics, coding, and AI concepts.
Education & STEM Applications
FX Navi is designed for project-based STEM learning across classrooms and independent learning environments. Its development ecosystem can also support language and arts projects, robotics exploration, and AI-tutor-style interactive experiences.
Specifications
General Specifications
| Specification | Details |
|---|---|
| Brand | Faraday Future |
| Model | NAVI |
| Robot Type | Quadruped |
| Robot Use | Companion, Education, Research |
Physical Specifications
| Specification | Details |
|---|---|
| Height | 51.5 cm |
| Length | 11.2 cm |
| Width | 29.8 cm |
| Weight | ≈8 kg |
Mobility & Performance
| Specification | Details |
|---|---|
| Total Degrees of Freedom | 12 DOF |
| Active Joints | 12 |
| Maximum Speed | 2 m/s |
| Maximum Payload | Light payload |
| Terrain / Obstacle Clearance | Indoor flat ground; dynamic gait balance; max. obstacle clearance height 34 cm (≈13.4 in) |
| Maximum Rotation | 360°/s |
Connectivity & I/O
| Specification | Details |
|---|---|
| Connectivity | 4G, 5G, Bluetooth, Wi-Fi |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| 4G/5G Module | Yes |
| Power Outputs | 5V / 12V + USB |
Software & Development
| Specification | Details |
|---|---|
| Operating System | Linux + localized UI/UX (FF-developed) |
| Secondary Development | Supported |
| OTA Updates | Yes |
| Mobile App | Yes |
| Development Platforms | Brain Blocks, Create Studio, EAI Soul, EAI Scribe, EAI Studio, SDK/API |
| Development Interfaces | Open low-level interface + Python SDK for motion control, perception, and hardware-expansion APIs |
Battery & Power
| Specification | Details |
|---|---|
| Runtime | Up to 2 hours |
| Battery Capacity | ≈0.2–0.3 kWh |
| Battery Type | Lithium |
| Input Voltage | Compatible with US household power using a compliant plug |
| Battery Safety | Over-current, over-voltage, and over-temperature protection |
AI, Voice & Perception
| Specification | Details |
|---|---|
| Conversation / Voice Features | US-local LLM/VLM stack; multilingual voice interaction via phone; supports 50 languages |
| Voice & Personality | Customizable voice, personality, hobbies, and localized profiles |
| Wake Word | Wake-word-free interaction supported |
| Camera | Onboard perception via paired smartphone camera |
| Audio | Voice and audio interaction via smartphone and app |
| Display / Lighting | Display and expression via smartphone and app |
| Other Sensors | Perception via paired smartphone camera, microphone, and display; expansion ports for external sensors or hardware |
Autonomy & OTA
| Specification | Details |
|---|---|
| Autonomy | Command-driven autonomy |
| OTA Roadmap | Future upgrades, basic learning through OTA upgrades, and OTA/version management supported |
Controller & Accessories
| Specification | Details |
|---|---|
| Controller / Teleoperation | Mobile app + remote controller |
| Included Accessories | Robot, charger, remote controller |
Skill Packages
| Specification | Details |
|---|---|
| Standard Skills | Standard skill package included |
| Optional Skills | Premium Skills, Curriculum Skill, and add-on dog-head package listed by source |
What's in the Box
1 x Faraday Future FX Navi Quadruped Robot
1 x Battery Charger
1 x Remote Controller
1 x Split Ferrite Core (Snap-on Type)
